Coupling FCD-O
Specification parameters
| Single Diaphragm Clamp Coupling | |||||
| Model | Flange OD (mm) | Shaft Dia Range (mm) | Total Length (mm) | Max Torque (N·m) | Max Speed (min⁻¹) |
| FCD-16O | 16 | 3～6.35 | 22 | 0.8 | 10000 |
| FCD-20O | 20 | 4～8 | 25 | 1.4 | 9000 |
| FCD-25O | 25 | 5～12 | 30 | 2.4 | 8000 |
| FCD-32O | 32 | 6～15 | 38 | 4 | 7000 |
| FCD-42O | 42 | 10～20 | 45 | 9.6 | 6000 |
| FCD-48O | 48 | 12～25 | 54 | 16.4 | 4000 |
| FCD-19OP | 19.1 | 3～6.35 | 22.9 | 2 | 8000 |
| FCD-25OP | 25.4 | 5～10 | 31.8 | 4.4 | 6000 |
| FCD-29OP | 28.6 | 6～12.7 | 38.1 | 6.2 | 5000 |
| FCD-38OP | 38.1 | 8～15 | 41.3 | 15 | 4500 |
| FCD-51OP | 50.8 | 12～19 | 51 | 28 | 4500 |
