SAI18A
Solid Shaft Encoder
The SAI18A2.5 is widely used in various mechanical industrial control systemsIt meets the requirements of modern light industry for small size, light weight.and high precision, and is a cost-effective product of choice.
Specification parameters
| Model | SAI18A2.5 |
| Product Type | Solid-shaft Incremental Encoder |
| Outer Diameter | 18mm |
| Shaft Diameter | 2.5mm（Solid Shaft） |
| Resolution | 100, 160, 200, 300, 360, 400, 500, 512 (Customizable) |
| Supply Voltage | DC5V |
| Output Form | Voltage Output |
| Output Signal | Output of Phase A (one - way) |
| 90° Phase - shifted A & B Signals | |
| Z signal | |
| Maximum Speed | 6000r/min |
| Maximum Radial/Axial Load | 2.94N/4.9N |
| Operating Temperature | -20～85℃ |
| Protection Rating | IP50 |
